Standard Specifications

1. Temperature Sensing Element: CA (K)

2. Sensor core wire diameter (Ø): 06mm

3. Sensor total length (L): 1m, 1.5m, 2m, 3m, 5m

4. Thread Specification (B): 3# 3/8

[Optional Specifications]

1. . Temperature sensing element: □CA(K), □IC(J), □CC(T), □CRC(E), □PT100, □PT1000, □Single, □Dual, □Supports other customizations

2. Sensor core wire diameter (Ø): □0.3mm, □supports other sizes

3. Sensor Lead Length (L): Customizable in mm

4. Protective Tube Diameter (Ø): Customizable Ø

5. Housing material: □ SUS304, □ SUS316, □ SUS310, □ Other materials supported

6. Protective Tube Length (A): Customizable L

7. Thread Specification (B): □PT1/8"、□PT1/4"、□PT3/8"、□PT1/2"、□PT3/4"、□PT1"
   □PF1/8", □PF1/4", □PF3/8", □PF1/2", □PF3/4", □PF1
   □ Supports other thread types

8. Maximum Temperature: Customizable (°C)

9. Other options: Customization supported

   For products and specifications not listed in the table above, please contact us for more information.
   * Products and specifications not listed in the table above are available upon request.
   ※ For products and specifications not listed in the table above, please inquire separately.
