RVC Series Cycloidal Pinwheel Precision Reducer
Model:RVC Series (10CBX, 27CBX, 50CBX, 100CBX/120CBX, 200CBX, 320CBX, 500CBX)
Origin:Made in China
The RVC series offers a variety of base and structural specifications, including the standard RVC model.
RVC-P and its derivatives such as 320CA-RVC. Optional standard center gear,
Also supports input gear design based on servo motor shafts. Hollow structure available for configuration.
The low-speed shaft is used for cable threading and sealing grease within the reducer.
Product Overview
The RVC series cycloidal precision reducers feature a compact, high-precision transmission design. Available in models from 10CBX to 500CBX, they are compatible with center gears, input gears, and servo motors.
Designed for high precision, concentricity, and parallelism with hollow routing and sealing capabilities. Ideal for high-precision, high-reliability industrial drive systems.
Product Specifications
Product Series: RVC Series
Main Models: 10CBX / 27CBX / 50CBX / 100CBX / 120CBX / 200CBX / 320CBX / 500CBX
Special models: 120CBX-RVC-P / 320CA-RVC
Drive type: Cycloidal pinwheel precision transmission
Configuration: Servo motor + Input gear + Center gear
Center distance tolerance: ±0.03mm
Concentricity tolerance: Max. 0.03mm
Parallelism tolerance: Max. 0.03mm
Hollow cable routing: Supported; low-speed conduit configurable
Sealing Method: O-ring or Liquid Sealant
Standard center gear: Optional (specify when ordering)
Grease filling: internal space approximately 70～90%
Grease replacement interval: approximately 2000 hours
Typical Use Cases
Servo motor precision transmission systems, industrial robot joints, precision rotary tables, automated equipment rotation axes, hollow cable routing mechanisms, and other industrial equipment requiring high assembly accuracy and transmission stability.
